| Specification | Details |
|---|---|
| Brand | ARB |
| Application | Toyota Hilux Mk8-9 Double Cab 2016-2020 |
| Quantity | One vehicle-specific kitchen and drawer package |
| Configuration | with Roller Floor |
| Kitchen housing | 1355 × 500 × 310 mm; kitchen module, not full load-bay package |
| Kitchen internal dimensions | 1250 × 485 × 190 mm |
| Bench | 1250 × 485 mm stainless steel |
| Bench load | 30 kg evenly distributed |
| Cooktop | Thetford LPG; two 1.75 kW burners and one 2.5 kW burner |
| Sink | 12 L collapsible sink with drying base and utensil holder |
| Utensil drawer | 450 × 345 × 145 mm |
| Closure | Key-lockable slam-shut latches |
| Stove load | 20 kg |
| Sink-platform load | 15 kg |
| Drawer extension | 115% on the RDK1355 kitchen |
| SKU / part number | XGSOUBTOH8KIRK |
Pull up somewhere good. Put the kettle on.
With the kitchen fitted in your Hilux, a stop for lunch can be a chance to enjoy the view instead of unpacking half the load bay. Slide out a proper stainless worktop, bring out the three-burner hob and keep cooking essentials in their own drawer. This package also includes a roller floor, giving you sliding access to correctly secured cargo above the drawer system. This package is for 2016-2020 Hilux Double Cab models.
SKU: XGSOUBTOH8KIRK
The 1250 × 485 mm stainless bench gives you space to prepare ingredients beside the cooker, with a 30 kg evenly distributed load limit. The Thetford hob has two 1.75 kW burners and a 2.5 kW rapid burner: boil water while another pan is cooking, or prepare more than one part of a meal together. Its glass lid becomes a splashback when open. Flame-out protection cuts the gas if a flame goes out, and closing the lid also shuts off the supply.
The utensil drawer gives cutlery and small cooking essentials a place to stay between stops. The 12 L collapsible sink, drying base and utensil holder make washing up part of the same cooking space. The kitchen locks in its extended position, with anti-rollback drawer features and anti-rattle construction for touring. Deployment takes around 15 seconds, before connecting the gas and preparing to cook. There are no support legs to position underneath, leaving the space around the kitchen clear.
The roller floor is included. It adds a sliding top for access to supported cargo, such as a separately supplied fridge secured in the appropriate mounting arrangement. Supplied equipment includes the slide-out kitchen, Outback drawer system, three-burner stove and collapsible sink. Food, cookware, a fridge and the LPG cylinder are separate.
Professional fitting is recommended. Installation includes drilling for the kitchen mountings, with enough space behind the tailgate for full extension. Use the LPG hose and regulator that match the supplied hob and cylinder, and cook outdoors with the extension locks engaged.
After the meal, let the cooker cool, disconnect the gas supply and secure the hob and sink shelf before sliding the kitchen away. You can leave the main cooking equipment organised in its own fitted space, rather than repacking a collection of loose items. Wipe the stainless surfaces with a soft cloth and a suitable non-abrasive cleaner, particularly after salt exposure. Check the fixings and latches before a trip and during the annual inspection.
For regular touring, the appeal is having the bench, cooker, sink and storage ready together at each stop. You trade some load-bay space and payload for that repeated convenience. A portable stove and table remain a simpler choice for occasional use. Allow room behind the tailgate for the extended kitchen and keep the total carried load within the vehicle's limits.
For UK customers, prices include VAT, customs and delivery unless checkout states otherwise. For customers outside the UK, local customs and taxes remain your responsibility, and shipping is shown at checkout. If a shipping option is not available, email us and we will prepare a tailored quote.
Many of the products we sell are made to order, imported or custom built, so a lead time may apply. If you need a part urgently, contact us before ordering and we will confirm the expected delivery timeframe and process.
Yes. The three-burner Thetford stove is included with the slide-out kitchen. The LPG cylinder is separate.
The included sink is a 12 L collapsible bowl. This package does not supply an onboard water tank or pump.
Yes. You can use the extended bench without opening the full cooking arrangement, staying within the 30 kg evenly distributed limit.
This version includes the rolling cargo top for easier access to supported equipment. The other Hilux kitchen package omits it.
No. The 1355 × 500 × 310 mm dimensions are for the kitchen housing. The complete drawer package and mounting must be matched to the vehicle’s load bay.
No. Extend and lock the kitchen for outdoor use, with the cooker arranged as directed in its instructions.
Yes. The kitchen and drawers are a fitted installation, using cargo space and some payload. In return, the cooking equipment stays organised and accessible at each stop. It suits regular touring best, when that convenience is worth dedicating the space to it.
Yes. The hob box can be unbolted and rotated during installation to suit access from the other side. Have its locks, clearances and gas connection checked in the chosen position.
For the ready-to-use cooking space around the stove: a substantial preparation bench, a sink, storage and a fitted home for the equipment. You still connect the gas and prepare the cooker at each stop, but there is less separate furniture and loose equipment to set out.
Model year, engine, drivetrain, hardware and existing modifications can all change what fits. Check the applications and supplier notes above, or send us your exact vehicle and setup before ordering.
Send us your vehicle, year, current setup and any fitting date, event, trip or deadline before ordering. We will help check fitment, product choice and timing.
